Remote Control Lawn Mower Video
Products Specification
| Parameter | Specification |
| Product Name | Remote Control Slope Lawn Mower |
| Model | LM-KJ1000 |
| Dimension | 1600 × 1220 × 890 mm |
| Overall weight | 370 kg |
| Cutting width | 1000 mm |
| Cutting height | 20 - 150 mm |
| Remote control distance | 200 m |
| Walking speed | 5 km/h |
| Voltage and electrical capacity | 24V 40AH |
| Start mode | Manual / Electric / Remote |
| Climbing angle | 45° |
| Power generation method | Self generation |
| Power | 15 hp |
| Mowing efficiency | 4000 m²/h |
Products Details
Front-Mounted Open Cutting Deck
Features
The cutting deck protrudes ahead of the tracks, complemented by a curved front bumper and an upper horizontal guard rail.
Advantages
Cutting with no blind spots. It allows for mowing right up against tree bases, wall corners, or obstacle edges without the tracks crushing the grass; the curved bumper pushes aside brush and protects the blades.
Side Belt Drive
Features
Engine power is efficiently transmitted to the front cutting deck via pulleys and a drive belt housed within the grey side casing.
Advantages
Smooth power transmission with built-in protection. The belt drive offers overload buffering (slip protection); if the blades jam against a hard object, the belt slips to prevent the engine crankshaft from snapping due to sudden impact.
Tracked Undercarriage
Features
Utilizes rubber tracks with multiple load-bearing wheels; the chassis is wide with a large ground contact area.
Advantages
Exceptional off-road capability. The wide tracks and multiple load-bearing wheels significantly reduce ground pressure, preventing slipping or getting stuck in mud, potholes, or on steep slopes exceeding 40°.
Integrated Roll Cage
Features
A grey metal roll cage at the top fully encloses core components such as the engine and battery.
Advantages
Comprehensive safety protection. It effectively shields core components from damage caused by flying stones, branches, or falling trees, ensuring the machine's durability in harsh outdoor environments.
Products Advantages
1. Gets the job done fast
With 15 horsepower and a 1-meter-wide cutting deck, it covers 4,000 square meters per hour. It finishes in no time a task that would exhaust a person for a whole day.
2. Goes anywhere
Equipped with a tracked chassis, it handles muddy ground, wetlands, and 45-degree slopes with ease-no getting stuck.
3. Rugged and durable
Features a metal roll cage to withstand falling branches; if the cutting deck hits a hard object, the drive belt slips to protect the engine from damage.
4. No operator discomfort
Operate it via remote control from up to 200 meters away-stay in the shade while you work. No breathing in dust or exhaust fumes, and no getting bitten by mosquitoes.
5. Ready to work anytime
Can't start the engine in winter? With three starting methods-manual pull-start, key ignition, and remote start-it's ready to go whenever you need it. It generates its own power while running, so there's no worry about running out of juice.
Products Application
1. Orchards/Plantations
Apple orchards, citrus groves, tea plantations, vineyards.
2. Slopes/Woodlands
Embankments, steep hills, and land converted from farming back to forest.
3. Wetlands/Pond Edges
Riverbanks, areas around ponds, canal sides, and reed beds.
4. Municipal/Landscape Maintenance
Open park spaces, highway medians, wasteland, and large lawns.
5. Firebreaks
Forest edges, areas around power infrastructure, and flammable grassy wasteland.
Starting Procedure of Remote Control Slope Lawn Mower
1.
Increase the throttle.
2.
Press and hold the engine decompression button.
3.
Turn on the Remote Control Slope Lawn Mower's main power switch..
(Do not release the decompression button.)
4.
Turn the ignition key to start the engine.
(Do not release the decompression button.)
5.
Once the engine speed picks up, release the decompression button.
