Orca Intelligent Equipment Co., Ltd. is one of the leading manufacturers and suppliers of all wheel steer skid steer in China. With abundant experience, we are committed to providing high quality customized service for global clients. Please feel free to buy discount all wheel steer skid steer from our factory.
Product Overview
An all wheel steer skid steer is a practical choice for jobs where space is limited and easy maneuvering matters. It handles loading, site cleanup, and landscaping, while compatible attachments allow it to work with different materials. When choosing a model, buyers should consider steering performance, lifting capacity, hydraulic compatibility, and maintenance needs.
Technical Specifications
| Parameter | Value |
| ENGINE | |
| Engine Brand | Briggs & Stratton 25T2 |
| Rated Power & Speed | 13.5HP/3600rpm |
| Fuel Tank Capacity | 28L |
| Hydraulic Oil Tank Capacity | 20L |
| Optional Engine Configurations (Stage II / EPA / Euro V) | Briggs & Stratton 25T2 / Hox:390 /Honda Staiton25T2/ Honda GX390 / Runtong 420cc / Kopu 192 / Changchai 192 |
| PERFORMANCE PARAMETERS | |
| Max. Load Capacity | 380KG |
| Bucket Capacity | 150L |
| Max. Digging Force | 450Kg |
| Travel Speed | 0-5.5Km/h |
| Machine Net Weight | Wheel Type: 710kg / Track Type: 780kg |
| Traction Force | 520KG |
| Gradeability Angle | 30° |
| PRODUCT PARAMETERS | |
| Max. Operating Height | 2200mm |
| Max. Pin Height | 1900mm |
| Max. Dump Height | 1560/1800mm |
| Max. Dump Reach | 348mm |
| Dump Angle | 55° |
| Rollback Angle | 30° |
| Bucket Rollback Angle (Ground Position) | 25° |
| Departure Angle | 11° |
| Overall Height | 1350mm |
| Ground Clearance | 100mm |
| Wheelbase | 860mm |
| Overall Length (Without Bucket) | 1780mm |
| Overall Width | 1200mm |
| Bucket Width | 1190mm |
| Overall Length (With Bucket) | 2500mm |
| Turning Radius | 1307mm |
| TIRE / TRACK MODEL | |
| Herringbone Industrial Tire | 18*8.5-8 |
| Track Model | 180/60/46 |
| EXPORT PACKING | |
| Fumigation-Free Wooden Case Packing | 2070*1250*1460mm |
| Stackable Steel Frame Packing | 2190*1200*2540mm |
Materials and Structural Design
The all wheel steer skid steer uses a structural steel frame built to handle regular loading and daily work. Reinforced lift arms and attachment mounting points provide added support during operation. Wear-resistant steel can be used on bucket edges to reduce wear from contact with rough materials. Hydraulic hoses, cylinders, and fittings are selected to match the machine's working pressure. For outdoor use, check the protective coating, seals, hose condition, and access to service points to help keep maintenance manageable.
Typical Applications
Construction Sites
Move sand, gravel, soil, and other materials around foundations, buildings, and renovation areas.
01
Agricultural Work
Handle feed, manure, bales, and loose materials when paired with suitable attachments.
02
Landscaping
Transport soil, clear vegetation, and prepare ground for planting or other outdoor work.
03
Warehousing and Yards
Move palletized goods or organize materials in compact storage and loading areas, subject to the machine's capacity and attachment suitability.
04
Municipal Maintenance
Assist with debris removal, property maintenance, and general site preparation.
05
Services and Support
Model Selection
Help compare machine capacity, dimensions, engine specifications, and hydraulic performance based on your work requirements.
Configuration Support
Recommend compatible attachments and optional features for different applications.
Technical and Maintenance Support
Provide available operating manuals, technical details, spare parts information, and maintenance guidance.
Export and Shipping Services
Discuss packaging, shipping arrangements, and export documents according to your destination and order requirements.
